PVC-C CORZAN® Industrial Grade sheet is a high heat, corrosion resistant chlorinated polyvinyl chloride sheet (CPVC). Because of its excellent corrosion resistance at elevated temperatures, it is ideally suited for self-supporting constructions where high temperatures are a concern. It can be used (depending on chemistry) up to 210° F. It is available in 4′ x 8′ sheets in thickness up to 3″.
• Chemical processing temperatures up to 200° F
• Machine flanges
• Valves
• Acid tanks
• Linings
• Easily to fabricate, weld or machine
• Color consistent
• Excellent impact strength, high temperature
• Excellent chemical and corrosion resistance
• Meets ASTM D-1784-99 Type IV Grade II Class 24446-B.
• Meets ASTM E 84 Flame Spread Rate 20.
• Maximum application temperature 200° F.
• Custom lengths, sizes, and special requirements available upon request.
| PART | THICKNESS (MM) | WT PER SHEET (LBS) | |
|---|---|---|---|
| CPVC-4' X 8' | |||
| S180211 | 1/8 | 32.50 | |
| S180311 | 3/16 | 48.75 | |
| S180411 | 1/4 | 65.00 | |
| S180511 | 3/8 | 97.50 | |
| S180611 | 1/2 | 130.0 | |
| S180711 | 3/4 | 195.0 | |
| S180811 | 1 | 260.0 | |
| S180911 | 1 1/4 | 325.0 | |
| S181011 | 1 1/2 | 390.0 | |
| S181111 | 2 | 520.0 | |
| S181211 | 3 | 780.0 | |
