High-Quality Conductivity Sensors by Icon Process

Products

Liquid Monitoring

MODEL	C250	C350	C450	C550
MEASURING RANGE	0- 2µ5 \| o – 1oµs	o – 20µ5 \| o – 2ooµs \| 0 – 2,000µS	0 – 100µ5 \| 0 – 1,000µS 0 – 10,000µS \| 0 – 200,000µS	0 – 10,000 µS/cm
MEASUREMENT METHOD	Bipolar
ELECTRODE CONSTANT	K = 0.01		K = 0.01 \| 0.1 \| 1.0 \| 10	K = 1.0
MATERIAL	Titanium Alloy	316L Stainless Steel	Titanium Alloy	Graphite + PMMA
TEMPERATURE	32 – 176°F	32 – 266°F	14 – 176°F
PRESSURE	0 – 150Ps	0 – 80Ps i	0 – 150Psi	0 – 100Psi
TEMPERATURE SENSOR	Ptl000 (std)
CONNECTION	NPT ¾”	Sanitary Tri-Clamp	NPT¾”
STANDARD CABLE LENGTH	5m
CABLE CONNECTION	J-Box I Flying Lead	Flying Lead	J-Box I Flying Lead

MODEL	C554	C650	C750	C850	C950
MEASURING RANGE	0-500,000 µS/cm	o – 100µ5 I o – 1,000µS 0 – 10,000µS I 0 – 200,000µS	0 – 2,000mS	o – 500,000 µS/cm	0 – 100µ5 I o – 1,000µS 0 – 10,000µS I 0 – 200,000µS
MEASUREMENT METHOD	Quadrupole		Bipolar
ELECTRODE CONSTANT	K = 0.01	K = 0.01 \| 0.1 \| 1.0 \| 10	Toroidal	K = 0.4	K = 0.Ql I 0.1 I 1.0 I 10
MATERIAL		Titanium Alloy	PFA Teflon® \| PP	Graphite + PMMA	Stainless Steel
TEMPERATURE		32 – 176°F	14 – 266°F	14 – 176°F	14 – 250°F
PRESSURE	0 – 90Ps		0 – 150Psi
TEMPERATURE SENSOR	NPT ¾”
CONNECTION
STANDARD CABLE LENGTH	5m
CABLE CONNECTION	J-Box I Flying Lead		Flying Lead	J-Box I Flying Lead	Flying Lead
