Icon Process Conductivity Controllers by Fabco Plastics

Products

Liquid Monitoring

MODEL	C300	C500	C700
RANGE	0 – S00ms/cm
RESOLUTION	0.0lµS/cm; 0.OlmS/cm
ERROR OF INDICATION	±0.5%F.S
STABILITY	±0.2%F.S/24h
TEMPERATURE	0 – 150.0°C (Electrode Specific )
TEMPERATURE RESOLITION	0.1 °C
TEMPERATURE	±0.3°C
TEMPERATURE COMPSENSATION RANGE	0 – 150°C
TEMPERATURE COMPSENSATION	Automatic or Manual
OUTPUT CURRENT	Two (2) x 4 – 20mA Outputs
COMMUNICATION	RS485 Modbus
DATA RECORDING	–	Data Recording/Trend Chart Display
RELAY CONTROL CONTACT	Two (2) Relays: 3A Outputs	Three (3) Relays: 5A Outputs
OPTIONAL POWER SUPPLY	85 – 265VAC or 9 – 36VDC
WORK ENVIRONMENT	Avoid magnetic field interference
ENVIRONMENT TEMPERATURE	14 – 140° F I -10 – 6o0c
RELATIVE HUMIDITY	90%
PROTECTION GRADE	IP65		NEMA 4X, IP66
MOUNTING HOLE SIZE	92.5 x 92.5mm	138 x 138mm	235 x 185 x 120mm
INSTALLATION	Panel I Wall I Pipe Mount		Wall Mount
